Forklift Drive Axle

Drive Axle Forklift - The piece of equipment which is elastically fastened to the frame of the vehicle with a lift mast is the lift truck drive axle. The lift mast affixes to the drive axle and can be inclined, by at the very least one tilting cylinder, around the drive axle's axial centerline. Frontward bearing elements combined with rear bearing parts of a torque bearing system are responsible for fastening the drive axle to the vehicle framework. The drive axle can be pivoted round a swiveling axis oriented transversely and horizontally in the vicinity of the rear bearing components. The lift mast can also be inclined relative to the drive axle. The tilting cylinder is attached to the lift truck frame and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented practically parallel to a plane extending from the swiveling axis to the axial centerline.

Lift truck units like H35, H40 and H45 that are produced in Aschaffenburg, Germany by Linde AG, have the lift mast tilt capably attached on the vehicle framework. The drive axle is elastically attached to the lift truck framework utilizing a multitude of bearing tools. The drive axle contains a tubular axle body together with extension arms attached to it and extend backwards. This particular kind of drive axle is elastically connected to the vehicle frame using back bearing elements on the extension arms along with frontward bearing devices located on the axle body. There are two back and two front bearing tools. Each one is separated in the transverse direction of the vehicle from the other bearing tool in its respective pair.

The drive and braking torques of the drive axle on tis particular unit of forklift are sustained utilizing the extension arms through the back bearing parts on the frame. The forces produced by the lift mast and the load being carried are transmitted into the floor or roadway by the vehicle frame through the front bearing parts of the drive axle. It is vital to be certain the parts of the drive axle are put together in a firm enough method to be able to maintain immovability of the lift truck truck. The bearing elements can lessen slight bumps or road surface irregularities throughout travel to a limited extent and offer a bit smoother operation.
